e-Bike Typ |
e-Mountainbike |
Modelljahr |
2017 |
Motorunterstützung |
25 |
Schaltung Hersteller |
Shimano |
Schaltungstyp |
Kettenschaltung |
Federung |
Fully |
Bremsentyp |
Hydraulische Scheibenbremse |
Farbe |
schwarz, orange |
Rahmengröße |
17'', 19'', 21'' |
Reifengröße |
27,5'' |
Rahmenform |
MTB Fullsuspension |
Motor |
Yamaha PW-X 36V 250W |
Akku |
500 Wh |
Schaltung |
Shimano XT, 11-Gang |
Schalthebel |
SHIMANO BR-M615, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180 |
Umwerfer |
SHIMANO SLX FD-M7020D, DIRECT MOUNT, SIDE SWING |
Schaltwerk |
SHIMANO XT RD-M8000 GS SHADOW PLUS DESIGN, TOP NORMAL, DIREC |
Kurbelsatz |
FSA CK745/ISIS, BOOST, 38-28 TEETH |
Kassette |
SHIMANO CS-M7000, 11-42 THEETH, 11-SPEED |
Kette |
SHIMANO CN-HG601-11 |
Rahmen |
ALLOY 6061 D.B., 140mm TRAVEL, 27.5''+ |
Gabel |
FOX 34 FLOAT PERFORMANCE 29'', 15mm AXLE, TAPERED, FIT4, TRAVEL: 140mm, 3-POSITI |
Steuersatz |
FSA NO. 57, 1-1/8'' UPPER AND 1.5'' LOWER BEARING WITH 8mm T |
Dämpfer |
FOX FLOAT DPS PERFORMANCE, LV, EVOL, 3 POS, 190mm LENGTH, HA |
Bremsanlage |
SHIMANO BR-M615, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180 |
Bremshebel |
SHIMANO BL-M615 ISPEC B |
Felgen |
ALEXRIMS XM-35, 32 HOLES, INNER WIDTH 35mm, 27.5'' |
Naben (V/H) |
SHIMANO DEORE HB-M618-B / 32 HOLES |
Reifen |
SCHWALBE NOBBY NIC PERFORMANCE LINE, 27.5x2.8'' |
Lenker |
LEVELNINE Race, 740mm, 9° ANGLE, 15mm RISE, 31.8mm |
Vorbau |
LEVELNINE RACE, BARBORE: 31.8mm, 1 1/8'', ANGLE:6° |
Sattelstütze |
KIND SHOCK LEV INTEGRA, 17'' & 19'': 125mm, 21'': 150mm TRAV |
Pedale |
WELLGO WAM-M18 |
Sattel |
SELLE ROYAL, SUEZ PERFORMA |
EAN |
7,61E+12 |
Artikelnummer |
101-002-7152-226-17 |
Gewicht |
22,9 kg |
Zulässiges Gesamtgewicht |
130 kg |
