| e-Bike Typ |
e-Mountainbike |
| Modelljahr |
2017 |
| Motorunterstützung |
25 |
| Schaltung Hersteller |
Shimano |
| Schaltungstyp |
Kettenschaltung |
| Federung |
Fully |
| Bremsentyp |
Hydraulische Scheibenbremse |
| Farbe |
schwarz, blau |
| Rahmengröße |
17'', 19'', 21'' |
| Reifengröße |
29'' |
| Rahmenform |
MTB Fullsuspension |
| Motor |
BionX D-Series 48V 250W |
| Akku |
555 Wh |
| Schaltung |
Shimano XT, 11-Gang |
| Schalthebel |
MAGURA MT-4E, HYDRAULIC DISC BRAKE, 180mm ROTORS |
| Umwerfer |
SHIMANO SLX FD-M7025E, E-TYPE, TOP SWING |
| Schaltwerk |
SHIMANO XT RD-M8000 SGS SHADOW PLUS DESIGN, TOP NORMAL, DIRE |
| Kurbelsatz |
SHIMANO XT FC-M8000-2, HOLLOWTECH II, 38-28 TEETH |
| Kassette |
SHIMANO CS-M8000, 11-42 THEETH, 11-SPEED |
| Kette |
SHIMANO CN-HG601-11 |
| Rahmen |
ALLOY 6061, BIONX SEMI INTEGRATED HYDROFORMED TUBING, TNT, TAPERED |
| Gabel |
MANITOU MARVEL COMP, 29'''', TAPERED, AIR SPRING, 15mm AXLE, 100mm TRAVEL, REBOU |
| Steuersatz |
GLORYWHEEL SI-25118ZALM |
| Dämpfer |
MANITOU RADIUM EXPERT, 190mm LENGTH, HYDRAULIC DAMPING, EXTE |
| Bremsanlage |
MAGURA MT-4E, HYDRAULIC DISC BRAKE, 180mm ROTORS |
| Bremshebel |
MAGURA MT-4E, WITH AUDIO JACK PLUG |
| Felgen |
ALEXRIMS FR-30, 32 HOLES, 29'' |
| Naben (V/H) |
SHIMANO XT HB-M758 / 32 HOLES |
| Reifen |
CONTINENTAL MOUNTAIN KING 29.5x2.20'' |
| Lenker |
LEVELNINE Race, 700mm, 9° ANGLE, 15mm RISE, 31.8mm |
| Vorbau |
LEVELNINE RACE, BARBORE: 31.8mm, 1 1/8'', ANGLE:6° |
| Sattelstütze |
LEVELNINE Race, 31.6x350mm |
| Pedale |
VP 195 |
| Sattel |
SELLE ROYAL SIRIO MAN 1204HRN |
| Gewicht |
21,9 kg |
| Zulässiges Gesamtgewicht |
130 kg |
