| e-Bike Typ |
e-Mountainbike |
| Modelljahr |
2017 |
| Motorunterstützung |
25 |
| Schaltung Hersteller |
Shimano |
| Schaltungstyp |
Kettenschaltung |
| Federung |
Hardtail |
| Bremsentyp |
Hydraulische Scheibenbremse |
| Rahmengröße |
15'', 17'', 19'' |
| Reifengröße |
27,5'' |
| Rahmenform |
MTB Hardtail |
| Motor |
BionX D-Series 48V 250W |
| Akku |
555 Wh |
| Schaltung |
Shimano XT, 10-Gang |
| Schalthebel |
MAGURA MT-4E, HYDRAULIC DISC BRAKE, 180mm ROTORS |
| Umwerfer |
SHIMANO DEORE FD-M618-B-IL, LOW CLAMP, TOP SWING, 34.9mm CLA |
| Schaltwerk |
SHIMANO XT RD-M781D SGS SHADOW DESIGN, DIRECT MOUNT TYPE, 10 |
| Kurbelsatz |
SHIMANO DEORE FC-M617, 2-PIECE CRANKSET, 36-22 TEETH |
| Kassette |
SHIMANO CS-HG50, 11-36 TEETH, 10-SPEED |
| Kette |
SHIMANO CN-HG54 |
| Rahmen |
ALLOY 6061, BIONX SEMI INTEGRATED HYDROFORMED TUBING, 27.5'', TAPERED |
| Gabel |
SUNTOUR RAIDON XC LO-R AIR 27.5'', 15mm, TAPERED, 100mm TRAVEL, REBOUND, HYDRAUL |
| Steuersatz |
GLORYWHEEL SI-25118ZALM |
| Bremsanlage |
MAGURA MT-4E, HYDRAULIC DISC BRAKE, 180mm ROTORS |
| Bremshebel |
MAGURA MT-4E, WITH AUDIO JACK PLUG |
| Felgen |
ALEXRIMS EN-24, 32 HOLES, 27.5'' |
| Naben (V/H) |
SHIMANO XT HB-M758 / 32 HOLES |
| Reifen |
CONTINENTAL MOUNTAIN KING 27.5x2.20'' |
| Lenker |
LEVELNINE Race, 660mm, 9° ANGLE, 15mm RISE, 31.8mm |
| Vorbau |
LEVELNINE RACE, BARBORE: 31.8mm, 1 1/8'', ANGLE:6° |
| Sattelstütze |
LEVELNINE Race, 31.6x350mm |
| Pedale |
VP 195 |
| Sattel |
SELLE ROYAL SIRIO LADY 1204DRN |
| Gewicht |
20,9 kg |
| Zulässiges Gesamtgewicht |
130 kg |
