| e-Bike Typ |
e-Mountainbike |
| Modelljahr |
2017 |
| Motorunterstützung |
25 |
| Schaltung Hersteller |
Shimano |
| Schaltungstyp |
Kettenschaltung |
| Federung |
Fully |
| Bremsentyp |
Hydraulische Scheibenbremse |
| Farbe |
schwarz, rot |
| Rahmengröße |
17'', 19'', 21'' |
| Reifengröße |
27,5'' |
| Rahmenform |
MTB Fullsuspension |
| Motor |
Yamaha 36V 250W |
| Akku |
500 Wh |
| Schaltung |
Shimano XT, 10-Gang |
| Schalthebel |
SHIMANO BR-M395, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180 |
| Umwerfer |
SHIMANO SLX FD-M676, DOWN SWING, 34.9mm CLAMP |
| Schaltwerk |
SHIMANO XT RD-M786 SGS SHADOW PLUS DESIGN, TOP NORMAL, 10-SP |
| Kurbelsatz |
FSA CK-745/ISIS, 42-32 TEETH, WITH YAMAHA SPYDER ARM |
| Kassette |
SHIMANO CS-HG500-10, 11-34 TEETH, 10-SPEED |
| Kette |
SHIMANO CN-HG54 |
| Rahmen |
ALLOY 6061 D.B., 140mm TRAVEL, 27.5'' |
| Gabel |
MANITOU MINUTE COMP, 27.5'', TAPERED, AIR SPRING, 15mm AXLE, 140mm TRAVEL, REBOU |
| Steuersatz |
GLORYWHEEL SI-25118ZALM |
| Dämpfer |
MANITOU RADIUM EXPERT, 190mm LENGTH, HYDRAULIC DAMPING, EXTE |
| Bremsanlage |
SHIMANO BR-M395, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180 |
| Bremshebel |
SHIMANO BL-M425 |
| Felgen |
ALEXRIMS MD-21, 32 HOLES, 27.5'' |
| Naben (V/H) |
SHIMANO DEORE HB-M618 / 32 HOLES |
| Reifen |
CONTINENTAL X-KING 27.5x2.40 |
| Lenker |
LEVELNINE Race, 720mm, 9° ANGLE, 15mm RISE, 31.8mm |
| Vorbau |
LEVELNINE RACE, BARBORE: 31.8mm, 1 1/8'', ANGLE:6° |
| Sattelstütze |
LEVELNINE RACE , 12mm OFF SET, 31.6x400mm |
| Pedale |
WELLGO C-015 |
| Sattel |
SELLE ROYAL, SUEZ PERFORMA |
| Gewicht |
22,7 kg |
| Zulässiges Gesamtgewicht |
130 kg |
