| e-Bike Typ |
e-Mountainbike, S-Pedelec |
| Modelljahr |
2017 |
| Motorunterstützung |
45 |
| Schaltung Hersteller |
Shimano |
| Schaltungstyp |
Kettenschaltung |
| Federung |
Fully |
| Bremsentyp |
Hydraulische Scheibenbremse |
| Farbe |
weiss, schwarz |
| Rahmengröße |
17'', 19'', 21'' |
| Reifengröße |
27,5'' |
| Rahmenform |
MTB Fullsuspension |
| Motor |
Yamaha 36V 500W |
| Akku |
500 Wh |
| Schaltung |
Shimano XT, 10-Gang |
| Schalthebel |
SHIMANO BR-M395, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180 |
| Umwerfer |
SRAM X5, HIGH CLAMP, 34.9mm |
| Schaltwerk |
SHIMANO XT RD-M786D SGS SHADOW PLUS DESIGN, DIRECT MOUNT TYP |
| Kurbelsatz |
FSA CK-745/JIS WA362+WB082+W1543 48/36T |
| Kassette |
SHIMANO CS-HG50, 11-36 TEETH, 10-SPEED |
| Kette |
SHIMANO CN-HG54 |
| Rahmen |
ALLOY 6061 D.B., 140mm TRAVEL, 27.5'' |
| Gabel |
MANITOU MINUTE COMP, 27.5'', TAPERED, AIR SPRING, 15mm AXLE, 140mm TRAVEL, REBOU |
| Steuersatz |
GLORYWHEEL SI-25118ZALM |
| Dämpfer |
MANITOU RADIUM EXPERT, 190mm LENGTH, HYDRAULIC DAMPING, EXTE |
| Bremsanlage |
SHIMANO BR-M395, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180 |
| Bremshebel |
SHIMANO BL-M425 |
| Felgen |
ALEXRIMS MD-21, 32 HOLES, 27.5'' |
| Naben (V/H) |
SHIMANO DEORE HB-M618 / 32 HOLES |
| Reifen |
CONTINENTAL X-KING 27.5x2.40 |
| Lenker |
LEVELNINE Race, 720mm, 9° ANGLE, 15mm RISE, 31.8mm |
| Vorbau |
WBP DA-230, ALLOY, BARBORE: 31.8mm, DIA:11/8'', ANGLE:6°, FO |
| Sattelstütze |
WHEELER SP-264TLA+TLA001, INCL NUMBER PLATE HOLDER |
| Pedale |
WELLGO LU-C015 |
| Sattel |
SELLE ROYAL, SUEZ PERFORMA |
| Frontlicht |
SUPERNOVA M99 PURE, 500 LUMEN, 160 LUX |
| Rücklicht |
SUPERNOVA M99 PURE, LED ECE50 |
| Gewicht |
23,5 kg |
| Zulässiges Gesamtgewicht |
130 kg |
