| e-Bike Typ |
City e-Bike, Trekking e-Bike, S-Pedelec |
| Modelljahr |
2017 |
| Motorunterstützung |
45 |
| Schaltung Hersteller |
Shimano |
| Schaltungstyp |
Kettenschaltung |
| Federung |
Federgabel |
| Bremsentyp |
Hydraulische Scheibenbremse |
| Farbe |
weiss, schwarz |
| Rahmengröße |
48, 52, 56, 60 |
| Reifengröße |
28'' |
| Rahmenform |
Trapez |
| Motor |
Yamaha 36V 500W |
| Akku |
500 Wh |
| Schaltung |
Shimano Deore, 10-Gang |
| Schalthebel |
SHIMANO BR-M365, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180 |
| Umwerfer |
SHIMANO DEORE FD-T611L, DOWN SWING, 34.9mm CLAMP |
| Schaltwerk |
SHIMANO DEORE RD-T610 SGS TOP NORMAL DESIGN, 10-SPEED |
| Kurbelsatz |
FSA CK-745/JIS WA362+WB082+W1543 48/36T |
| Kassette |
SHIMANO CS-HG500-10, 11-34 TEETH, 10-SPEED |
| Kette |
SHIMANO CN-HG50 |
| Rahmen |
ALLOY 6061 D.B. |
| Gabel |
ROCK SHOX PARAGON GOLD, TAPERED, 65mm TRAVEL, REMOTE LOCKOUT |
| Steuersatz |
FSA NO. 57, 1-1/8'' UPPER AND 1.5'' LOWER BEARING WITH 8mm T |
| Bremsanlage |
SHIMANO BR-M365, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180 |
| Bremshebel |
SHIMANO BL-M365 |
| Felgen |
ALEXRIMS DM-21, 36 HOLES |
| Naben (V/H) |
SHIMANO HB-RM33 / 36 HOLES |
| Reifen |
CONTINENTAL E-CONTACT 700X42C |
| Lenker |
WBP ARC AL540 EN-C, 600mm/31.8mm |
| Vorbau |
WBP AS-08 OS, BARBORE:31.8mm, ADJUSTABLE 0-60° |
| Sattelstütze |
WBP SP-382 EN-M, ALLOY, 27.2X350mm, 40mm TRAVEL |
| Pedale |
VP 615, ALLOY, ANTI SLIP |
| Sattel |
SELLE ROYAL FRECCIA FEMALE |
| Frontlicht |
SUPERNOVA E3 PURE, 165 LUMEN, STANDLIGHT AUTOMATIC |
| Rücklicht |
INTEGRATED IN CARRIER, STANDLIGHT AUTOMATIC |
| Gepäckträger |
RACKTIME I-VALO WITH INTEGRATED REAR LIGHT |
| Schutzbleche |
SKS CAB B53 |
| Gewicht |
23,9 kg |
| Zulässiges Gesamtgewicht |
130 kg |
